Yamaha XS 750 Touring

Read more about this motorcycle. Specification, detail, pictures and video. Please comments and give rating, tell others about it. Feel free to look around, we open 24 hours a day.

Make ModelYamaha XS 750 Touring
Year: 1977
Engine: Air cooled, four stroke, transverse three cylinder, DOHC, 2 valves per cylinder.
Capacity: 747
Bore x Stroke: 68 ? 68.6 mm
Compression Ratio: 8.5:1
Induction: 3x 34mm Mikuni carbs
Ignition / Starting: Electronic TCI / electric
Max Power: 64 hp @ 7500 rpm
Max Torque:
Transmission / Drive: 5 Speed / shaft
Front Suspension: Telescopic forks
Rear Suspension: Dual shocks swing arm, preload adjustable
Front Brakes: 2x 267mm discs
Rear Brakes: Single 267mm disc
Front Tire: : 3.25-19
Rear Tire: : 4.00-18
Dry-Weight: 331 kg
Fuel Capacity: 15 Litres
Consumption average42.9 mp/g
Braking 60 – 0 / 100 – 0- / 138 ft
Standing ΒΌ Mile 14.1 sec / 91.1 mp/h
Top Speed106 mp/g
ReviewsYamaha Magazine Articles
ManualXS750 Service Manual 1976-1977 / Yamaha Manuals Site / 1976 XS750D – 1977 XS750-2D Parts Manual / 1977 XS750-2D Owners Manual / 1981 XS850H Parts Manual

The second version of Yamaha’s shafty is smoother, faster, cheaper and has more ground clearance than the original D — and it’s just as comfortable.
